Chinese Design Style Geocomposite Drainage Sheet with CE/ISO9001/ISO14001 Certificate

Product Description

Professional Supplier Geocomposite Drainage Sheet for landfills

Chinese Design Style Geocomposite Drainage Sheet with CE/ISO9001/ISO14001 Certificate

Drainage Net, also called Composite Geonet,

Drainage Net, also called Composite Geonet, is a two or three-layer three-dimensional drainage geosynthetic product which are often made with polypropylene PP or regenerated HDPE (geonet) and covered with double-sided thermally heat-bonded nonwoven geotextile on both sides or one side. It has excellent performance than traditional draining gravel. So it becomes a good alternative for gravel in drainage application. Our drainage net is widely used for landfill, railway system drainage, road drainage, tunnel and retaining wall.

3D composite drainage network

Composite Drainage Network is a new type of dewatering geotechnical material, which the raw material is HDPE and manufactured via particular extrusion forming technique. It has three levels, the inner fillet has strong rigidity, arrange longitudinal to form dewatering channel, the upper and bottom fillet form support to avoid geotextile inserting into dewatering channel, that means even if under high load it can also keep good dewatering property. It is the best dewatering material currently who has below function:" filter -- dewatering -- ventilate -- protect".

The geonet has high drainage performance which is made of high quality polyethylene resin, adding 2-3% carbon black, anti-UV and anti-oxidant processed by special extruding technology. The 3D composite drainage net combines the characteristics and functions of geonet and geotextile, it has the
comprehensive charateristics of anti-filtration, good drainage, air permeability and high strengthen and protection reinforcement.It is an ideal new drainage geo material.

Specification

Property	Unit	BC63/D200	BC70/D200	BC80/D200	BC90/D200	Test Standard
Hydraulic conductivity (MD)	m2/s	2.8×10-3	3.2×10-3	4.0×10-3	5 x10-3	ASTM D4716
Puncture Resistance	KN/m	0.17	0.17	0.17	0.17	ASTM D7005
Thickness	mm	6.3	7	8	9	ASTM D5199
Density	g/cm-3	0.94	0.94	0.94	0.94	ASTM D1505
Carbon Black Content	%	2	2	2	2	ASTM D1603
Tensile strength (MD)	kN/m	8	10	12	14	ASTM D7199
Hydraulic conductivity (MD)	m2/s	8	10	12	14	ASTM D4716
Unit weight	g/m2	200	200	200	200
Geotextile type	Continuous filament non-woven geotextile

Machines

Product Application

Application

1. Landfill drainage;

2. Roadbed and road drainage;

3. Railway drainage, tunnel drainage, underground structure drainage.

4.Theretaining back wall drainage,

5. Gardens and sports grounds drainage

Packing & Delivery

Packed in roll and woven bags

Company Profile

Shandong Yibo Yangguang engineering materials co., LTD. Is a collection of product research, development, production, installation and after-sales service into a comprehensive high-tech enterprises. The company mainly produces various specifications, geotextile, composite geomembrane, geogrid, HDPE geomembrane, bentonite waterproof blanket, prevent aging geotechnical woven bag and all kinds of geotechnical material such as dust-proof net, sun-shade net, woven bag. The company has advanced two production lines for the non-woven equipment is 6.6 meters, 6.6 meters composite membrane equipment, each a film equipment, blow molding machine, bentonite waterproof blanket equipment each a number, warp knitting machine, wire drawing machines. Company's products have been widely used in roads and railways, Bridges, tunnels, libraries, canal water conservancy anti-seepage, reclamation of levelling, landfill, mining area, and many other industries, salt industry, chemical industry, agriculture and fisheries. In each big in the field of engineering construction has stood the test of various engineering conditions, obtained satisfactory result of engineering, won the customer consistent high praise.

FAQ

1. who are we?
We are based in Shandong, China, start from 2016,sell to North America(40.00%),Western Europe(20.00%),South Asia(20.00%),Northern Europe(10.00%),Eastern Europe(5.00%),Africa(5.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Geomembrane,Geotextile,GCL Liner,3D Composite Drainage Geonet,Composite Geomembrane

4. why should you buy from us not from other suppliers?
shandong yibo yangguang engineering materials co., ltd is with more than 20 years in producing geomembrane, geotextile, compsite geomembrane, gcl l iner, etc. we expecting to cooperate with you and hope that you can visit our factory to talk more.

5. what services can we provide?
Accepted Delivery Terms: FOB；
Accepted Payment Currency:USD;
Accepted Payment Type: 30%deposit ,the blance is before the delivery
Language Spoken:English,Chinese
